Mainly to look at temperament! CANTV Super TV F55 Reviews
[PConline Professional Evaluation] China's traditional television manufacturers are actively linking with all aspects of the Internet. Internet TV has become the mainstream TV product in the market. We hope to transform from "manufacturing" to "creation", and the upstart TV and LeTV in the TV industry. In addition, high-profile, low-cost, and content-rich waves have emerged in the market. In addition, PPTV has been put up for sale, and micro-whale TVs and popular televisions have also appeared one after another. They have entered the television industry across the border in an attempt to gain a share.
CANTV F55 Picture Evaluation Forum Quotation Net purchase price
As one of the seven Internet TV integrated broadcast control licensees, the Guangdong side also cuts into the field of smart TV manufacturing, and jointly invested with Dahua Smart to set up Global Zhida Technology to build its own smart terminal brand CAN, and at the same time release CANTV super TV A series of products, aggregating a number of network-wide video resources, the first CANTV super TV C49S on the Suning Mall online, instantly sold out. After the ironclad hit, CIBN once again launched a new launch of the CANTV Super TV F55, creating a "most understand your UI system."
CANTV F55 Main Parameter Model CANTV Super TV F55 Processor MSD6A828 64-bit Core Processor (1.4GHz) Memory 2GB DDR3 High Speed ​​Memory8GB NAND eMMC high-speed storage screen size / inch 55 resolution 3840 × 2160 audio technology original CVS surround sound technology, DOLBY decoding technology, image quality technology 178 ° wide viewing angle technology, GG grayscale enhancement, edge sharpening technology, suspended noise removal, Advanced Anti-Aliasing Technology Operating System Blue Shadow UI 4.0 Interactive System Main Interface USB×2, RJ45 Network Interface×1, HDMI×3, Fiber Interface×1, Audio Interface×1, VGA Input, SD Card Slot Size/mm 1233.2× 711.6×62mm (without base) Weight/kg 21.4kg (with base) Reference price/yuan 3999 yuan
CANTV F55 uses a very narrow border design, with a 15.5mm slim body and 7.9mm ultra-narrow frame, and incorporates Eastern design and cultural elements, a unique Tai Chi Bisui map modeling base; invited a team of renowned domestic film masters personally school Color, provides viewers with rich movie quality and color effects. In UI, equipped with Azure 4.0UI system, the system is based on massive video and big data cloud computing capabilities, users can complete the depth of content customization. The brand new terminal product brand relies on the full range of resources of CIBN Internet TV to create the home television intelligent service ecosystem of “video + smart applications + games + TV shoppingâ€.
CANTV Super TV F55: Appearance
CANTV Super TV F55 spent a lot of thought on the appearance, using the popular narrow border design, followed by the classic black tones, the lower border supplemented by silver small border embellishment, the base is combined with the Oriental element design, with Tai Chi Pisces map Designed for prototypes, it brings a different sense of beauty.
CANTV Super TV F55 back shell design layout is very simple and regular, but also designed a special five-dimensional button, can replace some remote control operation.
CANTV Super TV F55 uses a very narrow frame design, injection molding border edging, classic black color scheme, simple without losing luxury, the narrowest border is only 7.9mm.
The design of the base is also considered by many manufacturers. The model is based on the Tai Chi Pisces diagram, and the appearance of silver makes it possible to improve the art of finishing. The power switch is designed with a toggle switch.
The interface is very rich in TV products, out of standing HDMI interface, USB interface, but also configure the component input interface, VGA interface and support for SD card reading.
The standard remote control retains the number buttons, making the remote control body size larger, and also adding the traditional navigation remote control navigation key design.
Summary: Although not appearance control, but the appearance is always the most direct to attract consumers, CANTV Super TV F55 uses a very narrow frame design, enabling the classic black color scheme, the difference in the design of the base and the market products to The Tai Chi Pis map is a prototype, which gives it the temperament of oriental elements and brings a different aesthetic experience.
CANTV Super TV F55: Color Performance
Evaluation room to get the evaluation prototype, the use of professional equipment to conduct a detailed test, in the test, the first TV picture display to standard image mode, backlight adjustment to the brightest, other parameters design default, CANTV Super TV F55 All test items and scoring results We have made the five-dimensional performance charts on the map.
Evaluation results as shown above, in the color adjustment, CANTV Super TV F55 has been tested, its color gamut is as high as 79.334%, high color gamut performance is undoubtedly derived from its use of LG original IPS hard screen. Unlike some products on the market that use the WRGB 4 color pseudo 4K panel, the pixel density is 1.5 times that of the pseudo 4K panel, the picture will be clearer, and the color transition will be more natural and delicate. In terms of average brightness, the average brightness of the CANTV Super TV F55 also reached a high level of 278cd/m2.
Power performance test
CANTV Super TV F55 Power Consumption Test Model/Frame Red Green Blue Black and White Color Transition CANTV Super TV F55 140.88w 142.31w 137.06w 128.12w 146.65w 141.25wIn energy consumption, CANTV Super TV F55 uses RGB 4K panels, but its brightness value is not low, coupled with its 55-inch large-screen display, power consumption performance of around 130W, performance is very good.
The instrument has been tested and the CAN color TV F55 has a color gamut of 79.334%, a high saturation, and a high degree of color reproduction. The color transition is also very natural and delicate. From the bottom left pixel, it can be judged that this is using the LG Display panel, which matches the officially announced information.
In terms of color consistency, after repeated testing, the test result of CANTV Super TV F55 is the same, the test instrument shows a pass, the brightness uniformity and the color difference can be seen from the figure is very good, showing that the factory calibration of the panel is also to force.
In the silk standard test screen, we can see that the color reproduction ability of the CANTV Super TV F55 is very good, the colors are also soft and natural, and the different shades of the same color can be well distinguished, without serious deviation. Color appeared, and the texture of the silk sewing thread was very clear.
The standard test screen of yarn ball has been to compare whether there is a bond area between the red and pink yarn balls on the lower right side and whether the picture has whitening. From the test screen, CANTV Super TV F55 has performed well. The reproduction of colors is in place, with no adhesion areas and color deviations.
In the standard test of the girl's test with roses, the skin color of the figure is natural, and there is no such thing as whitening. The protagonist's hair ends are naturally connected with clothes, no color blocks appear, and the screen is very delicate.
Summary: Integrated data testing and standard test disc screen shots, CANTV Super TV F55 color reproduction is very accurate, the color gamut value of 79.334% can be considered at the same level in the middle. Through the observation of the standard proofs, the color reproduction of the picture is natural and the degree of saturation is also high. For complex pictures, the details are retained.
CANTV Super TV F55: Optical Control Performance
In the brightness test session, the TV backlight setting needs to be adjusted to the highest, and other settings are the default. CANTV Super TV F55 average brightness of up to 278.67cd/m2, the performance of the white screen is very colorful, detailed description of the details of the screen does not say that the difference between the white under different gray values ​​is obvious, the screen of the object's dark side of the performance is also very To force, the entire screen has a strong sense of hierarchy.
For the average user, you can directly see the quality of the TV panel calibration through the black screen. When the surrounding environment is completely black, when the TV screen is turned to black, you can directly see the degree of light leakage. This is also the most direct judgment TV panel. Excellent calibration, all black case, CANTV Super TV F55 light leakage phenomenon is not obvious, there is a little white in the lower right corner, but the overall very uniform. In fact, light leakage is an inevitable phenomenon for all LCD TVs, but light leakage will not affect the quality and life of LCD TVs.
In terms of grayscale performance, due to the camera exposure, the effect of the photo display is not very obvious. In the black part, the boundary between 0~1th order and 14~15 is slightly blurred, and other parts are clearly visible to the naked eye.
The black and white background of the standard test disc, the two women's satin evening dresses stand on the same color background, the outline of the clothes of the clothes can be distinguished from the background color, and will not be integrated with its background; Tokyo Tower part, sky There was no light leakage, and there was a clear gap between the billboards. The charcoal part was mainly to see if the side lines were preserved. From the test screen, the black sinks down and still retains the details.
Summary: Under normal circumstances, the RGB 4K screen pixel density will increase the brightness of the picture will be reduced, but from the test point of view, CANTV Super TV F55 brightness value is still maintained at 278cd/m2, the latter screen calibration is quite strong, although there is a slight light leakage and Evenly, the dark part of the black part of the picture sinks down, while the details are not lost. The entire picture is full of layers. The following dynamic test, the high-speed motion picture, how to retain the details?
High-speed dynamic picture test
In this test section, from the perspective of 100% enlargement, we can see whether the scenery on the other side of the train is clear through the train window to determine the merits of its dynamic performance. From the real shot of the screen of the CANTV Super TV F55 High-speed passing trains have clear outlines of the roofs of the houses on the other side of the windows. The figures in the carriages can also be clearly distinguished and there are no cases of smearing or blurred objects.
From the test results and standard test discs, we can see that the dynamic test performance of CANTV Super TV F55 is considered as a high level performance in the same class of products, and the overall performance is good. Next, look at other screen shots.
Summary: In the actual screen capture process, whether it is dynamic display, or static screen, or the color of the complex picture, the speed of response to ensure that the picture in high-speed movement, the details can be fully preserved. On the whole, the dynamic effect of the CANTV Super TV F55 is outstanding in this price TV.
Local multimedia test
Local multimedia playback is the most basic and most demanding function of smart TVs. The decoding method is very important and needs to be guaranteed most. High-definition decoding capabilities rely on powerful configuration and excellent system optimization. The author uses a 32G USB 3.0 USB flash drive to ensure sufficient transmission speed and test it. Test video files first. The supported formats cover the current popular formats, including AVI, FLV/F4V, WMV/ASF, 3GP/3G2/3GPP, MP4/M4VMPEG/MPG/DAT/VOB/EVO/VOB, TS/ M2TS, MKV/WEBM, MOV, etc.
HD video format encoding compatibility table (non-H.265) video name encoding format resolution bit rate playback Beijing Roast Duck full version MPEG-4 MP4 3840×2160 32.3Mbps perfect play duck fly AVC MKV 3840×2160 248Mbps Perfect Play Transformers 4 Announcements MPEG-4 MP4 3840×2160 125kbps Perfect Play Boots for Cats RV40 RMVB 1280×720 1490Kbps Perfect Play Hellfire WMV3 WMV 1920×1080 8000Kbps Perfect Play Ice Age 3 V_MPEG4 MKV 1920×1036 12.5Mbps Perfect Play Dark Knight V_MPEG4 MKV 1920×1080 11.3Mbps Perfect Play Eason2010 Guangzhou Concert AVC MKV 1920×1080 10.0Mbps Perfect Play Transformers 2 MPEG-4V MP4 1920×1080 8439Kbps Perfect Play Green Leaves MPEG2 TS 1920×1080 19.4Mbps Perfect Play Final Fantasy MPEG4 MKV 1920×1080 7621Kbps Perfect Play
For the mainstream format mp4, mkv, rmvb, CANTV super TV F55 said no pressure. Picture colors and light and shadow are all portrayed in detail, and their H.265 video decoding and playback capabilities are not negligible. Compared with the H.264 decoding method, 50% of the bandwidth is saved.
HD Video Format Coding Compatible Table (H.265) Video Name Encoding Format Resolution Rate Playback K-ON!! the Movie Matroska MKV 1920×1080 600.4kbps Perfect Play Space Station Earth MPEG-4 FLV 3840×2160 23.8Mbps Perfect Play Byzantium MPEG-4 mp4 1280×544 801 Kbps Perfect Play Arthur.Newman MPEG-4 mp4 1280×536 535 Kbps Perfect Play Hell Man MPEG-4 mp4 1280×720 2394 Kbps Perfect Play Avengers Preamble MPEG-4 mp4 1280×720 2261 Kbps Perfect Play BattleShip MPEG-4 mp4 1280×720 2368 Kbps Perfect Play
Summary: Through the actual test, CANTV Super TV F55's video decoding capability is very satisfactory, in the process of playing, regardless of MKV or high-definition videophile friendly TS format, the playback process has a very good fluency, high-speed picture Smear does not appear, support H.265 hard decoding, compared to H.264 decoding mode saves 50% of the bandwidth, combined with its many image processing technology and high dynamic contrast, so that the picture quality is more delicate, more saturated colors .
Blue ShadowTM System UI/Summary
Cross-border entry into the TV manufacturing industry has attracted consumers' attention not only in terms of their hardware configuration or design, but also in terms of the characteristics of their system UI and how rich their resources are. The CANTV in these areas is full of confidence. It has customized the Blue Shadow TMUI interactive system for CANTV super TVs, built specifically for large-screen displays, with a streamlined interface, and added intelligent search, WeChat interaction and many other interactive experiences, not to talk nonsense, and experience again. It.
It can be seen that the main interface design is very simple, dynamic display using large modules, divided into signal source, recommendation, classification, carousel, games and set up six sections, and its distribution order or interface layout can be self-defined, will UI design initiative is also given back to consumers.
In the category section, resources are subdivided into TV dramas, movies, variety shows, etc., so that consumers can quickly locate the resource information they want.
ç…² ç…² å¯ å¯ å¯ å¯ å¯ TV TV TV TV TV TV TV TV TV TV TV CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN CAN The alliance, whether it is a hit TV series or a classic theater, can be watched on the CANTV F55.
While viewing, you can select an album through the menu, or you can design the display ratio and picture quality of the picture to achieve the best viewing effect.
The movie video library is also very large and classified in detail. It includes movies from Europe and the United States, as well as romantic love stories, and of course, animal martial arts and comedy.
TV dramas and movie content are rich enough, enough choices are available, and their variety shows are also quite rich. Natural reality shows are naturally no less. Challenger League, 12-channel taste, and sincere heroes can all be switched over. With the third quarter of the running season, you don't have to bother looking for resources to miss a particular episode.
"Star of China" is to build a high standard international musical feast as the standard, and the singer that finally wins will be able to climb onto the Grammy international music stage. In this music feast, CANTV Super TV as the official designated Internet TV to participate in the program cooperation, another point of view is also a valid proof of its strength.
CANTV Super TV F55 uses a special custom dual independent speaker, the industry's rare independent sound cavity design, sound waves in the sound cavity can be fully resonant, so that the sound is more powerful and rich, rich layering. It also supports the original CVS surround sound technology and DOLBY decoding technology, the most authentic restoration of each note of the music scene.
In addition, CANTV Super TV F55 also has a documentary, online drama, Zen culture and special topics, which will not be enumerated in detail.
The CANTV Super TV F55 also has a carousel function. It has rich video content and resources for CIBN Internet TV, and 17 carousel channels such as TV dramas, movies, animations, and variety shows, and is truly 24-hour uninterrupted.
As mentioned earlier, there is a game interface. Here, it is not a game platform. It is an e-sports live broadcasting platform created for game enthusiasts. It cannot go to the game to watch the game, nor can it pay attention to the display of a small screen. A 55-inch large-screen display No longer need to worry about the chaos of the battle scene.
Live all-star games, but also used to look at the small screen? The match between ice and fire is even less of a personal show.
The large-screen TV application is not better than the APP of the mobile phone. The CANTV super TV is optimized for large-screen TV display. The application covers games, education, and life services.
The author tried to download several games to experience. The simple and puzzle game uses the remote control to operate the experience is good, but like fighting and other fighting games, you need to use a professional Bluetooth remote control handle and TV match before you can experience.
Parenting and other educational resources are also quite rich. Children's imagination is developed for children's unique education and teaching videos of different ages.
CANTV Super TV F55 built-in Bluetooth 4.0 module, transmission distance up to 100 meters, no matter where you go to the house, you can easily use Bluetooth remote control, headphones, video on demand, listen to music. The unique BLE energy-saving technology allows your Bluetooth device to work more efficiently and last longer.
PConline evaluation room summary
2, RGB 4K screen
3, rich content resources
4, Blue Shadow UI4.0 interactive system
5, TEA game tea restaurant 1, the standard remote control design is more conservative
Targeting the high-end market, the CANTV Super TV F55 offer is only 3999 yuan, in the just past the double 12 is to play a discount + coupons only 3,499 of the world's best prices. Although the price is close to the people, the quality and configuration of the process have not been compromised. Cooperation with TPV Technology ensures the product quality. The high-end 64-bit quad-core processor also allows consumers to see CANTV Super TV in good faith. In terms of content, relying on the inherent advantages of CIBN's premium video content, it also integrates numerous first-line video platforms and has created unique Zen cultural channels, ChinaTV and other special features to provide consumers with more comprehensive video resources.
In order to cater to the viewing needs of young people today, it also launched the “TEA Game Tea Restaurant†game video resource platform, which has gathered high-impact electric competition events at home and abroad, such as HTS, NEST, Women’s DOTAS League, etc., with more than 100,000. Hours of e-sports game video, the industry's most authoritative game video aggregation platform, regardless of whether you are competing enthusiasts, choose CANTV Super TV F55 is excellent value for money.
